Knee type milling machine with ball lead screw in Z-axis for workpieces up to 1.000 Kg.
knee type milling machine FKM 5130
FKM 5130
table size
1800x500 mm
speeds
45-1800 U/min 17 Steps
max. weigth of workpiece
1500 kg
movement of X-axis manual/auto
1330/1320 mm
movement of Y-axis manual/auto
360/345 mm
movement Z-axis manual/auto
630/600 mm
tool mounts
Steilkegel ISO 50
quill stroke
90 mm
swivel range both side
+-45
min/max distance between
spindlenose - table
95-725 mm
distance spindle nose - column
450 mm
feeds for X+Y axis
16-800 mm/min 18 Steps
rapid feed X/Y-axis
3000 mm/min
autofeed Z-axis
5-250 mm/min 18 Steps
rapid feed Z-axis
1000 mm/min
power of engine
15 kW/ 400 Volt
connection value
25 KVA
quantity/size t-slots
6x18x63
weight
5500 kg
dimensions
2530x2194x2595 mm
Features
»
»
pneumatic drawbar
»
»
central lubrication with time intervall
»
»
control panel portable (corded remote control)
»
»
leadscrew in Z-axis for max. table load
»
»
extremely heavy construction
»
»
very stable boring quill
»
»
cooling device
»
»
3-axis-digital readout
