multi porpuse milling machine FKM 560
Universal milling machine for professional use with electromagnetic clutch for the drill feed and
thread cutting device.
FKM 560
table size
1120 x 260 mm
spindle speeds
67 - 2010 (V) / 40 - 1300
(H) U/min
drilling capacity in steel
40
movement longitudinal X
600 mm
movement cross Y
300 mm
movement in Z
350 mm
tool mounts
Steilkegel 40/ ISO 40
quill stroke
120 mm
size of t-slots
T14
power of engine
2,2 kW 400 Volt
weight
1300 kg
dimensions
1580 x 1450 x 2150 mm
Features
»
»
precise surface treated cross table
»
»
guide ways hardend and by V-ledge adjustable
»
»
adjustable counterbearing
»
»
central lubrication
»
»
forward/backward motor rotation
»
»
feed in X-/Y axis
»
»
Z-axiselektricallye quick adjustment
»
»
electromagnetic clutch for boring quill feed
»
»
cooling device
»
»
3-axis-digital readout
Abbildungen können abweichen.Technische Daten können ohne vorherige Ankündigung geändert werden. Keine Haftung für Irrtümer und Druckfehler.Alle Preise on request.
Accessories
»
»
ISO 40 collet chuck set
»
»
ISO 40 drill chuck arbor
»
»
drill chuck 1-13mm
