drilling and milling machine FKM 250
Drilling and milling machine with taper 30 tool holder. By precisely worked cross table with its
adjustable guideways the machine is ideal for precise milling jobs.
FKM 250
table size
730 x 210 mm
spindle speeds
100-2080 U/min
drilling capacity in steel
25 mm
drilling capacity in cast iron
32 mm
movement longitudinal X
500 mm
movement cross Y
230 mm
height adjustment milling head
340 mm
tool mounts
ISO 30 / SK 30
quill stroke
130 mm
diameter of coloumn
115 mm
size of t-slots
16 mm (T14)
distance spindle nose - column
202 mm
power of engine
1,1 kW 400 Volt
weight
300 kg
dimensions
1080 x 1010 x 1100 mm
Features
»
»
automatic x-axis feed
»
»
spindle transmission by gearbox
»
»
head pivotable by 90°
»
»
quill feed by engageable hand crank
»
»
spindle and quill mounted axially and radially for optimal milling
results
»
»
adjustable dovetail guideways in all 3 axis
»
»
forward/backward motor rotation
»
»
table feed by gearbox
»
»
taper 40 tool mounts
»
»
3-axis digital readout
Accessories
»
»
drill chuck arbor
»
»
drill chuck
Model also available in 230V.
