multi porpuse milling machine FKM 595
Universal milling machine for single part and spare parts production with variable
speed. The vertical head can be tilted in two axes.
FKM 570V
FKM 580V
FKM 580VL
spindle speeds
50 - 3600 U/min stepless 50 - 3600 U/min stepless 60 - 3600 U/min stepless
table size
230 x 1246 mm
254 x 1370 mm
254 x 1370 mm
working area
200 x 1000 mm
200 x 1200 mm
200 x 1200 mm
drilling capacity in steel
30 mm
30 mm
30 mm
movement longitudinal X
745 mm
800 mm
800 mm
movement cross Y
305 mm
405 mm
405 mm
movement in Z
360 mm
405 mm
405 mm
tool mounts
Steilkegel 40/ ISO 40
Steilkegel 40/ ISO 40
Steilkegel 40/ ISO 40
quill stroke
120 mm
120 mm
120 mm
size of t-slots
T14
T14
T14
power of engine
2,2 kW 400 Volt
3,75 kW 400 Volt
2,4 kW 400 Volt
weight
1000 kg
1200 kg
1200 kg
dimensions
1651x1701x2006 mm 1905 x 1879 x 2235 mm 1905x1879x2235 mm
Features
»
»
stepless speed transmitted by the variation system for
powerful spindle transmission
»
»
milling head pivotable 90° in both directions
»
»
engageable manual fine feed
»
»
spindle with SK 40 mounted axially and radially
»
»
guideways adjustable by V-ledges
»
»
forward/backward motor rotation
»
»
stepless feed for X+Y axis
»
»
electric quick adjustment for Z-axis
»
»
autom. boring quill feed
»
»
threading attachment
»
»
depth indicator with micrometer regulation
»
»
integrated cooling device
»
»
3-axis-digital readout
Accessories
»
»
ISO 40 collet chuck set
»
»
ISO 40 drill chuck arbor
»
»
160 mm machine vice
