BK 90
BK 110
BK 110
BK 110
BK 110
BK 130
table size
1000x800 mm 1010x1320 mm 1010x1320 mm 1010x1320 mm 1010x1320 mm 1600x1400 mm
max. weigth of work-
piece
2000 kg
5000 kg
5000 kg
5000 kg
5000 kg
8000 kg
T-slot
7-22-150
7-22-125
7-22-125
7-22-125
7-22-125
7-22-150
distance spindle nose
- work table
5-755 mm
5-905 mm
5-905 mm
5-905 mm
5-905 mm
5-1800 mm
movement longitudi-
nal X
850 mm
850 mm
1200 mm
1800 mm
120 mm
1500 mm
movement cross Y
755 mm
900 mm
900 mm
1200 mm
1200 mm
1600 mm
movement vertical Z
1080 mm
1300 mm
1300 mm
1300 mm
1300 mm
1400 mm
travel (w)
600 mm
550 mm
550 mm
550 mm
550 mm
900 mm
spindle speeds
20 - 1000 U/min
12 - 950 U/min (18)
12 - 950 U/min (18)
12 - 950 U/min (18)
12 - 950 U/min (18)
4 - 800 U/min (24)
speed faceplate feed
10 - 200 U/min
4 - 160 U/min
4 - 160 U/min
4 - 160 U/min
4 - 160 U/min
2,5 - 125 U/min
tool mounts
MK 5
ISO 50
ISO 50
ISO 50
ISO 50
ISO 50
spindlediameter
90 mm
110 mm
110 mm
110 mm
110 mm
130 mm
stroke of flat slide
170 mm
160 mm
160 mm
160 mm
160 mm
250 mm
stroke of spindle
450 mm
600 mm
600 mm
600 mm
600 mm
900 mm
autofeed X-axis
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,05 - 8 mm/U
autofeed Y-axis
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,05 - 8 mm/U
autofeed Z-axis
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,025 - 8 mm/U
0,01 - 2 mm/U
autofeed W-axis
0,05 - 16 mm/U
0,75 - 24 mm/U
0,75 - 24 mm/U
0,75 - 24 mm/U
0,75 - 24 mm/U
0,32 - 2500 mm/min
stroke of flat slide
-
0,05 - 16 mm/U
0,05 - 16 mm/U
0,05 - 16 mm/U
-
0,32 - 2500 mm/min
power
7,5 kW
11 kW
11 kW
11 kW
11 kW
15 kW
dimensions (LxBxH)
5075x2345x2730
mm
5347x2648x2889
mm
5347x3020x2889
mm
5347x3704x3344
mm
5347x3704x3344
mm
6995x3647x3100
mm
weight
12000 kg
13500 kg
15000 kg
20000 kg
20000 kg
24500 kg
Conventional boring machines for universal drilling and milling jobs for large workpieces.
horinzontal boring machines BK series
Features
»
»
all functionselektrically/Hydraulic geschaltet (nur BK 130)
»
»
360° rotating table
»
»
faceplate and boring spindle with independent speed ranges
»
»
optical Leseskala
»
»
stable rectangular guideways hardend and precisely ground
»
»
telescopic covers of the guide ways
»
»
central lubrication with time intervall
»
»
3-axis digital readout
Accessories
»
»
steady rest (at BK 130 optional)
All models of this series can also be
provided with a CNC control system.
