Pictures may differ. Specifications are subject to change without notice. No liability for errors and printing mistakes.All prices on request.
Center lathe with extensive features and sensational price/performance ratio. This entry-level
model leaves nothing to be desired.
lathes DKM 300
DKM 300
heigth of center
150 mm
distance between center
750 mm optional auch mit
914 mm lieferbar
max. swing over bed
300 mm
max. swing in the gap
430 mm
max. swing over slider
178 mm
diameter of spindlehole
38 mm
speed range
65 - 1810 U/min
range longitudinal feeds
0,052 - 1,392 mm/U
range cross feeds
0,014 - 0,38 mm/U
metric thread
0,4 - 7 mm
inch thread
4 - 56 TPI
quill stroke
100 mm
quill konus
MK 3
power of engine
1,5 kW 400 V
weight
500 kg
dimensions
1590 x 750 x 1270 mm
Features
»
»
38 mm spindle bore
»
»
hardened and ground gear for low-noise run
»
»
adjustable guideways by V-ledgen
»
»
adjustable main spindle bearing
»
»
automatic feed in longitudinal and cross
»
»
spindle break via food pedal
»
»
gap
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
3-jaw chuck 160mm
»
»
4-jaw independent chuck 200mm
»
»
steady and following rest
»
»
splash guard
»
»
thread dial indicator
»
»
auto feed stop block with Mikrometer
»
»
base
