Pictures may differ. Specifications are subject to change without notice. No liability for errors and printing mistakes.All prices on request.
Centre lathes with proven design equipped with manual spindle brake and micrometer-stop.
Years of experience and the precise workmanship make this machine model to one of the
best-selling imported machines.
lathes DKM 360er series
DKM 360
DKM 360V
heigth of center
180 mm
180 mm
distance between center
1000 mm
1000 mm
max. swing over bed
356 mm
356 mm
max. swing in the gap
506 mm
506 mm
max. swing over slider
220 mm
220 mm
diameter of spindlehole
38 mm
38 mm
speed range
45 - 1800 U/min
1./2. Gear stage 30 - 550 /
155 - 3000 U/min
spindlenose
DIN 55029 D1-4/MK 5
DIN 55029 D1-4/MK 5
range longitudinal feeds
0.043 - 0.653 mm/U; 42 Steps 0.043 - 0.653 mm/U; 42 Steps
range cross feeds
0.015 - 0.220 mm/U; 42 Steps 0.027 - 0.413 mm/U; 42 Steps
metric thread
0.4 - 7 mm; 37 Steps
0.4 - 7 mm; 37 Steps
inch thread
4 - 56; 28 Steps
4 - 56; 28 Steps
quill diameter
45 mm/MK3
45 mm/MK3
quill stroke
120 mm
120 mm
quill konus
Morse Konus 3
Morse Konus 3
power of engine
2.4 kW
2.4 kW
weight
900 kg
900 kg
dimensions
1945 x 785 x 1204 mm
1945 x 920 x 1585 mm
Features
»
»
stepless speed in 2 gear steps (nur DKM 360V)
»
»
38 mm diameter of spindlehole
»
»
gears hardend and ground
»
»
adjustable main spindle bearing
»
»
overload clutch for feed system
»
»
micrometer stop block
»
»
gap
»
»
mechanical spindle break
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
3-B Futter 160 mm (nur DKM 360)
»
»
4-jaw independent chucknfutter
200 mm
»
»
4-position toolholder for lathe
»
»
steady and following rest
»
»
dead center
»
»
chip tray
»
»
splash guard
»
»
micrometer stop block
