Robust lathe for industrial heavy duty usage with a large bed width of
600 mm and a one-piece machine bed.
lathe DKM 800 S
DKM 800 S
heigth of center
400 mm
distance between center
1500-6000 mm
bed width
600 mm
max. swing over bed
800 mm
max. swing over slider
480 mm
diameter of spindlehole
140 mm
spindlenose
DIN 55027 KK15
speed range forward
5.5 - 750 U/min
speed range backward
10 - 775 U/min
range longitudinal feeds
(64) 0,1 - 24.32 mm/U
range cross feeds
(64) 0,05 - 12.16 mm/U
metric thread
(50) 1 - 240 mm
inch thread
(26) 14 - 1 TPI
model thread
(53) 0,5 - 120 mm
diametral pitch
(24) 28 - 1 DP
quill diameter
100 mm
quill stroke
250 mm
quill konus
Morse Konus 6
power of engine
11 kW
weight
6600 kg (E.g. 3M)
dimensions
5160x1450x1630 mm (E.g. 3M)
Features
»
»
gear helically toothed
»
»
hardend and ground
»
»
hydraulic clutch
»
»
pressure adjustable
»
»
lubrication by integrated pump
»
»
adjustable main spindle bearing
»
»
rapid feed in longitudinal and cross
»
»
overload clutch in apron
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
3-jaws lathe chuck 500 mm
»
»
steady+following rest
»
»
splash guard
