Cheap Center lathe model for the single-part production and training purposes. The ribbed bed
ensures low-vibration operation. Simple speed changing through gear box.
lathe DKM 332
LATHES
DKM332
heigth of center
165 mm
distance between center
1000 mm
max. swing over bed
330 mm
max. swing in the gap
450 mm
max. swing over slider
178 mm
diameter of spindlehole
38 mm
spindlenose
DIN55029 D 1 - 4/MK 5
speed range
70 - 2000 U/min
range longitudinal feeds
0,0527 - 1,2912 mm/U
range cross feeds
0,014 - 0,3448 mm/U
metric thread
0,4 - 7 mm
inch thread
4 - 60 TPI
quill diameter
32 mm
quill stroke
100 mm
quill konus
MK 3
power of engine
1,1 kW / 400 Volt
weight
480 kg
dimensions
1870 x 720 x 1400 mm
Features
»
»
38 mm spindle bore
»
»
hardened and ground gear for low-noise run
»
»
adjustable guideways by V-ledgen
»
»
adjustable main spindle bearing
»
»
automatic feed in longitudinal and cross
»
»
gap
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
3-jaw chuck 160mm
»
»
4-jaw independent chuck 200mm
»
»
steady and following rest
»
»
splash guard
»
»
thread dial indicator
»
»
auto feed stop block with Mikrometer
»
»
base
