lathe DKM 630 S
Very heavy and powerful precision lathe with a bed width of 600 mm and 11 kW power. The
machine is comparable to a German machine because of its quality construction and its high
processing accuracy ! The high engine power and extremely heavy construction allows maximum
chip removals with best processing results.
DKM 630
heigth of center
315 mm
distance between center
1500/2000/3000 mm
max. swing over bed
630 mm
max. swing in the gap
-
max. swing over slider
400 mm
diameter of spindlehole
105 mm
spindlenose
DIN 55026 A1-11
speed range
12,5 - 1120 U/min
range longitudinal feeds
0,062 - 7 mm/U (56 Steps)
range cross feeds
0,031 - 3,5 mm/U (56 Steps)
metric thread
0,5 - 28 mm (31 Steps)
inch thread
1 - 56 TPI (38 Steps)
model thread
0,25 - 7 mm (21 Steps)
diametral pitch
56 - 4 DP (27 Steps)
quill diameter
100 mm
quill stroke
250 mm
quill konus
Morse Konus 5
power of engine
11 kW
weight
4200/4750/5300kg
dimensions
3500/4000/5000 x 1260 x 1385 mm
Features
»
»
bed width 600mm
»
»
gear helically toothed, hardend and ground
»
»
hydraulic clutch system
»
»
hydraulic spindle break
»
»
lubrication by integrated pump
»
»
manual central lubrication for Bettbahn
»
»
leadscrew and Support
»
»
adjustable main spindle bearing
»
»
rapid feed in longitudinal and cross
»
»
overload clutch in apron
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
3-jaw chuck 315mm
»
»
following and steady rest
