DKM 1000 S
DKM 1250 S
heigth of center
500 mm
625 mm
distance between center
1500-18000 mm
1500-18000 mm
bed width
755 mm
755 mm
max. weight of workpiece
6000 kg
6000 Kg
max. swing over bed
1000 mm
1250 mm
max. swing over slider
610 mm
865 mm
diameter of spindlehole
130 mm
130 mm
spindlenose
D1-15/Kurzkegel 15
A 215 (8xM22)
speed range
3.15 - 315 U/min (21 Steps)
Vorw
range longitudinal feeds
0.1 - 12 mm/U 57 Steps
(56) 0,1 - 12 mm/U
range cross feeds
0.05 - 6 mm/U 57 Steps
(56) 0,05 - 6 mm/U
rapid feed longitudinal/cross
3700/1850 mm/min
metric thread
1 - 120 mm
(44) 1 - 120 mm
inch thread
3/8 - 28 GPZ
(31) 28 - 1/4 TPI
model thread
0.5 - 60 mm
(45) 0,5 - 60 mm
diametral pitch
1 - 56 DP
(38) 56 - 1/2 DP
quill konus
MK 6
Morse Konus 6
quill diameter
160 mm
160 mm
quill stroke
300 mm
300 mm
power of engine
22 kW
22 kW
weight
15800 kg (E.g. 5M)
14800 kg (E.g. 5M)
dimensions
8350x2190x1810 mm (E.g. 5M) 8100 x 1825 x 2150 mm (E.g. 5M)
Features
»
»
electrically propelled tailstock (nur DKM 2400/2200/2000)
»
»
gear helically toothed, hardend and ground
»
»
hydraulic clutch system pressure adjustable
»
»
hydraulic spindle break pressure adjustable
»
»
lubrication by integrated pump
»
»
adjustable main spindle bearing
»
»
rapid feed in longitudinal and cross
»
»
overload clutch in apron
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
4-jaw independent chuck 2000 mm (DKM 2400)
»
»
4-jaw independent chuck 1800 mm (DKM 2200)
»
»
4-jaw independent chuck 1600 mm (DKM 2000)
»
»
4-jaw independent chuck 1250 mm (DKM 1600)
»
»
steady rest
»
»
following rest
»
»
rapid feed for Support
»
»
electrically moveable tailstock
Optional Accessories
»
»
Rollenbock
»
»
Zusätzliche Lünetten
Abbildungen können abweichen.Technische Daten können ohne vorherige Ankündigung geändert werden. Keine Haftung für Irrtümer und Druckfehler.Alle Preise on request.
