MILLING MACHINES
CNC
DRILLING MACHINES
SAWS
SHEET METAL PROCESSING
GRINDING
LATHES
Accessories
»
»
steady rest 140 - 200 mm (DKM400W)
»
»
steady rest 180 - 270 mm (DKM500W)
»
»
steady rest 250 - 400 mm (DKM630W)
»
»
steady rest 300 - 480 mm (DMK800W)
»
»
steady rest 300 - 600 mm (DKM1000W)
»
»
steady rest 400 - 750 mm (DKM1250W)
DKM 400 W
DKM 500 W
DKM 630 W
DKM 800 W
DKM 1000 W
DKM 1250 W
heigth of center
200 mm
250 mm
315 mm
400 mm
500 mm
625 mm
distance between center
2500 mm
2500 mm
2500/3200/4000/5000
mm
2500/3200/4000/5000
mm
on request
on request
bed width
670 mm
670 mm
1020 mm
1020 mm
1350 mm
1350 mm
machining length
2500 mm
2500 mm
2500 mm
2500 mm
max. swing over bed
400 mm
500 mm
630 mm
800 mm
1000 mm
1250 mm
guideways
3
3
3
3
3/4
3/4
max. workpice weigth
2,0 to
3,0 to
6,0 to optional 8 to
6,0 to optional 8 to
18 to
18 to
diameter of spindlehole
35 mm
35 mm
50 mm
50 mm
50 mm
50 mm
speed range
2 - 88 U/min;12
Steps
2 - 88 U/min;12
Steps
1 - 73 U/min; 16 Steps 1 - 73 U/min; 16 Steps 2 - 160 U/min
stepless
2 - 160 U/min
stepless
adapter toolholder for
lathe
80x25 mm
80x25 mm
80 x 25 mm
80 x 25 mm
range of swivel toolhol-
der for lathe
+- 90
+- 90
+- 90
+- 90
travel Top slider
200 mm
250 mm
360 mm
400 mm
320 mm
320 mm
rapid feed cross
1500 mm/min
1500 mm/min
1500 mm/min
1500 mm/min
585 mm/min
585 mm/min
rapid feed longitudinal
2800 mm/min
2800 mm/min
3600 mm/min
3600 mm/min
2000 mm/min
2000 mm/min
quill diameter
120 mm
120 mm
180 optional 200 mm 180 optional 200 mm 300 mm
300 mm
quill stroke
200 mm
200 mm
quill konus
MK 6
MK 6
Metric 65;1:7
Metric 65;1:7
Metric 651:7
Metric 651:7
power of engine
11 kW
11 kW
18,5 kW
22 kW
DC 55 kW
DC 55 kW
weight
6000 kg
6800 kg
13430 kg
14430 kg
35000 kg (E.g. 6M) 36000 kg (E.g. 5M)
dimensions
4660 x 1272 x
1300 mm
4660 x 1272 x
1300 mm
6250/6750/7750/8750 x
1580 x 1650 mm
6250/6750/7750/8750
x 1612 x 1910 mm
on request
on request
