Pictures may differ. Specifications are subject to change without notice. No liability for errors and printing mistakes.All prices on request.
DKM 800 WS
DKM 1000 WS
DKM 1250 WS
heigth of center
400 mm
500 mm
625 mm
distance between center
on request
on request
on request
bed width
1350 mm
1600 mm
1600 mm
machining length
on request
on request
on request
max. swing over bed
800 mm
1000 mm
1250 mm
guideways
3
3/4
3/4
max. workpice weigth
18 to
18 to
40 to
diameter of spindlehole
50 mm
50 mm
50 mm
speed range
2 - 160 U/min stepless
2 - 160 U/min stepless
2 - 160 U/min stepless
cutting force max.
50 kN
100 kN
130 kN
travel Top slider
200 mm
320 mm
320 mm
rapid feed cross
585 mm/min
585 mm/min
585 mm/min
rapid feed longitudinal
2000 mm/min
2000 mm/min
2000 mm/min
quill diameter
280 mm
300 mm
400 mm
travel quill
250 mm
300 mm
300 mm
tailstock drive
elektrisch
elektrisch
elektrisch
power of engine
DC 49 kW
DC 55 kW
DC 75 kW
weight
32000 kg (E.g. 4M)
45000 kg (E.g. 6M)
48000 kg (E.g. 5M)
dimensions
on request
roll turning lathe
The special design of the gearbox and the reinforced machine bed allows despite of the compact
construction the processing of very large workpiece weights and enable high chip removals .
All machines of the W and WS series are equipped with Turcite coated guides. In the production
of these machine models predominantly westerly component manufacturers are used. Various
options such as steel holder sizes, chip conveyors, power chucks with jaw boxes are available.
All machines of this series can also be pro-
vided with a CNC control system.
