The face lathes of the P series are all constructed for heavy processing.
face lathe
DKM 1500 P DKM 2000 P DKM 2500 P
turning diameter max. 1500 mm 2000 mm 2500 mm
max. working length 1000 mm 1000 mm 1000 mm
max. swing over bed 1500 mm 2000 mm 2500 mm
max. swing over slider 680 mm 1180 mm 1680 mm
spindlenose A 2/15 (8xM22) A 2/20 (8xM22) A 2/20 (8xM22)
speed range 2 - 200 U/min stepless 1 - 160 U/min stepless 1 - 125 U/min stepless
cross movement 820 mm 1024 mm 1024 mm
longitudinal movement 1000 mm 1000 mm 1000 mm
travel Top slider 400 mm 400 mm 400 mm
longitudinal feed 0.8 - 25 mm/min 0.8 - 25 mm/min 0.8 - 25 mm/min
cross feed 1.6 - 50 mm/min 1.6 - 50 mm/min 1.6 - 50 mm/min
rapid feed longitudinal 2500 mm/min 2500 mm/min 2500 mm/min
toolholder for lathe swivel-moun-
ted
360 360 360
power of engine 22 kW optional 30 kW 30 kW optional 37 kW 30 kW optional 37 kW
weight 8300 kg 8800 kg 9500 kg
dimensions 3800 x 2600 x 2200 mm 3800 x 3100 x 2700 mm 3800 x 3600 x 3200 mm
Accessories
» » 4-jaw independent chuck
