Competitively priced entry-level models for the hobby sector. Through the small operating Dimen-
sions even demanding turning operations can be performed in the smallest space.
bench-lathe DKM 220/250
DKM 220
DKM 250
heigth of center
110 mm
125 mm
distance between center
500 mm
700 mm
max. swing over bed
220 mm
250 mm
max. swing over slider
122 mm
130 mm
diameter of spindlehole
20 mm
27 mm
speed range
140 - 1710 U/min
115-1620 U/min
range longitudinal feeds
0,05 - 0,2 mm (5 Steps)
0,05 - 0,2 mm
metric thread
0,4 - 3 mm (17 Steps)
0,2 - 3,5 mm (20 Steps)
inch thread
8 - 48 TPI (17 Steps)
8 - 56 TPI (20 Steps)
model thread
-
0,2 - 1,25 (10 Steps)
swivel range of top slider
+-45
+-45
quill konus
MK 2
Morse Konus 2
quill stroke
20 mm
40 mm
power of engine
0,37 kW/400Volt
0,75kW/400 Volt
weight
110 kg
152 kg
dimensions
1085 x 588 x 450 mm 1410 x 605 x 405 mm
Features
»
»
adjustable guideways „by adjustable ledges“
»
»
Geschliffene gear in in Oil running for absolut low-noise run
»
»
hardened and ground gear for low-noise run
»
»
3-axis-digital readout optional
Accessories
»
»
3-jaw chuck 100mm
both models with 230 V version avail-
able. Additional accessories available !
