Universal bed type milling machine for large and heavy workpieces. The very wide flat bed guid-
ways grant stability and ensure precision at high table load.
bed type milling machine FKM 8150
FKM 8150
spindle speeds
40 - 1600 / 12 Steps
movement longitudinal X
1500 mm
movement cross Y
700 mm
movement in Z
0 - 700 mm
height adjustment milling head
0 - 700 mm
tool mounts
ISO 50/ Steilkegel 50
working area
2100 x 500 mm
distance spindle nose - column
610 mm
rapid feed
X+Y 3500 mm/min
power of engine
7,5 kW 400 Volt
weight
7000 kg
dimensions
3300 x 2380 x 2750 mm
Features
»
»
hardened and ground flat bed guideways for extremee work piece weights
»
»
big table working area
»
»
very big travel in X-axis (1500 mm)
»
»
universal swivel head System Huron
»
»
stepless feed in X+Y axis
»
»
telescopic covers for die Z-axis
»
»
cooling device
»
»
3-axis digital readout
Accessories
»
»
Arbor bolt
»
»
ISO 50 milling chuck
»
»
ISO 50 end mill arbour 40 mm
»
»
horizontal milling arbor 32 mm
