knee type milling machine FKM 580
Heavy universal milling machine with vertical milling head. The machine is equipped with an extra
large work area and has a horizontal and vertical working spindle. The vertical milling head can
be tilted 90 ° left / right.
FKM 580
table size
1320 x 320 mm
spindle speeds
(12) 58 - 1800 U/min
movement longitudinal X
750 mm automatisch/800 mm manuell
movement cross Y
300 mm
movement in Z
400 mm
tool mounts
vertikal ISO 40 / horizontal ISO 50
feed range of X,Y Axis
(8) 20 - 360 mm
distance spindle nose - work table
0-400 mm
distance spindle nose - column
175 mm
size of t-slots
T14
distance spindle nose - column
175 mm
power of main motor
4kW
enginepower feeding motor/z-axis
motor
0,55/0,75 kW
enginepower/flow rate of cooling pump
90 W/25 l/min
weight
2100 kg
dimensions
1900 x 1720 x 1750 mm
Features
»
»
precise, wide, ground and hardened rectangular guideways
»
»
swivel-mounted milling head 90° left/rigth
»
»
autofeed + rapid feed for X+Y axis
»
»
Z-axis positioning motor for quick justifying
»
»
mechanical axis clamping in all axis
»
»
heavily ribbed, massive cast iron design for vibration free processing
»
»
gearshift for den speed change
»
»
in oil running gear wheels hardend and ground
»
»
central lubrication
»
»
cooling device
»
»
3-axis digital readout
Accessories
»
»
ISO 40 milling chuck with collets
»
»
adapterMK4
»
»
end mill arbour 750mm/27mm
»
»
end mill arbour 750mm/40 mm
