universal tool milling machine 935 / 940 / 950
Strong Universal tool milling machine ideal for use in tool and mold making.
FKM 935
FKM 940
FKM 950
table size
700 x 280 mm
750x320 mm
800x400 mm
table load (max.)
300 kg
300 kg
300 kg
distance spindle nose - column
max. 540 mm
max. 540 mm
max. 540 mm
spindle speeds
150-1660 (vert.) / 110-1230
(hor.) U/min
40 - 2000 U/min (18 Steps)
40 - 2000 U/min
movement longitudinal X
300 mm
400 mm
500 mm
movement cross Y
200 mm
300 mm
400 mm
movement in Z
350 mm
400 mm
400 mm
rapid feed X,Y,Z-axis
1200 mm/min
1200 mm/min
1200 mm/min
tool mounts
ISO 40 / DIN 2080
ISO 40
ISO 40
quill stroke
80 mm
60 mm
80 mm
quill feed
-
0,03/0,06/0,12 mm/U
0,03 / 0,06 / 0,12 mm/U
size of t-slots
T14
14x63 mm
8 x 14 x 63 mm
power of engine
3,0 kW 400 Volt
3,0 kW 400 Volt
3,0 kW 400 Volt
weight
1150 kg
3000 kg
1400 kg
dimensions
1310 x 1380 x 1650 mm 1810 x 1220 x 2200 mm 1390 x 1430 x 1820 mm
Features
»
»
automatic feed for boring quill 3 steps (nur FKM 940/950)
»
»
finely tuned 18 stepped main spindle drive for optimal spindle speeds at
high torque
»
»
seperate finely tuned feeding gear with seperate transmission system and
rapid feeds in all axis
»
»
heavily ribbed machine body for rigidity and continously precision
»
»
swivel-mounted control panel for comfortable handling
»
»
boring quill adjustable by handle
»
»
hardened and ground guideways
»
»
automatic central lubrication
»
»
cooling device
»
»
3-axis digital readout
Accessories
»
»
ISO 40 end mill arbour
»
»
ISO 40 collet chuck set with collets
»
»
ISO 40 reduction
»
»
Arbor bolt
»
»
counter support
»
»
chip tray
