FKM 660
FKM 6100
working area/table size
1120x260 mm
1325 x 320 mm
spindle speeds
35-1600 U/min
58 - 1800 U/min (12 Steps)
spindle speeds horizontal
-
40 - 1300 U/min
movement longitudinal X
600 mm
1000 m
movement cross Y
270 mm
290 mm
movement in Z
400 mm
450 mm
tool mounts
ISO 40 / DIN 2080
ISO 40
size of t-slots
T14
14 mm
distance spindle nose - column
60 - 500 mm
200 - 760 mm
rapid feed
1000 mm/min
1200 mm/min
power of engine
2,2 kW 400 Volt
3,0 kW 400 Volt
weight
1360 kg
2100 kg
dimensions
1655 x 1325 x 1650 mm 1780 x 1970 x 1850 mm
Features
»
»
horizontal spindle with seperate gear drive simultanously switchable (nur FKM6100)
»
»
rectangular guideways in Y+Z-axis for big rigidity (nur FKM6100)
»
»
universal milling head for processing nearly any three-dimensional angle
»
»
heavy cast iron design for precise processing
»
»
adjustable guideways through V-ledges
»
»
high smooth running by hardened and ground gear
»
»
automatic feed in X+Y-axis
»
»
electric quick adjustment for Z-axis
»
»
manual central lubrication
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
collet chuck set with collets (nur FKM660)
»
»
counter support for Horizontalfräsen
»
»
draw bar (nur FKM6100)
»
»
long end mill arbour ISO40/27
»
»
ISO40/32 mm(nur FKM6100)
»
»
Adapter ISO 40/MK 3(nur FKM6100)
