multi porpuse milling machine 440
Drilling and milling machine with industrial character. The machine is designed for private and
commercial use. The massive and solid construction allows the use of an ISO 40 tool holder and
thus also the use of larger cutter heads.
FKM 440
table size
800x240 mm
spindle speeds
115-1750 U/min
drilling capacity in steel
35 mm
movement longitudinal X
400 mm
movement cross Y
230 mm
height adjustment milling head
350 mm
tool mounts
ISO 40 / DIN 2080
quill stroke
125 mm
size of t-slots
14 mm
distance spindle nose - column
320 mm
power of engine
1,5 kW 400 Volt
weight
560 kg
dimensions
1100 x 950 x 2090 mm
Features
»
»
automatic x-axis feed
»
»
spindle transmission by gearbox
»
»
head pivotable by 90°
»
»
quill feed by engageable hand crank
»
»
spindle and quill mounted axially and radially for optimal milling results
»
»
adjustable dovetail guideways in all 3 axis
»
»
forward/backward motor rotation
»
»
table feed by gearbox
»
»
taper 40 tool mounts
»
»
3-axis digital readout
Accessories
»
»
ISO 40 collet chuck set with collets
»
»
grey iron base
»
»
cooling device
»
»
3 axis DRO ready mounted
