LATHES
MILLING MACHINES
DRILLING MACHINES
SAWS
SHEET METAL PROCESSING
GRINDING
CNC
BKM 7150 CNC
sizes of worktable
1020 x 380 mm
distance spindle nose - work
table
max 680 mm
distance spindle nose - column
450 mm
spindle speeds
48 - 2000 U/min
drilling capacity in steel
63 mm
milling performance in Steel
80 mm
threadcutting volume
M42
movement longitudinal X
510 mm
movement cross Y
380 mm
height adjustment milling head
530 mm
tool mounts
BT 40
quill stroke
240 mm
size of t-slots
14 mm (M12)
power of engine
3,7 kW 400 Volt
weight
1800 kg
dimensions
1700x1510x2250 mm
Features
»
»
extremly wide and solid box frame construction made of cast iron for heavy duty applications
»
»
prism guideways for drilling head
»
»
motorized positioning of the drilling heades
»
»
stepless speed in 2 gear steps for optimal power transmission
»
»
threading attachment with adjustable depth indicator
»
»
central lubrication for extended lifecycle of the guideways
»
»
autofeed for quill
»
»
electromagnetic clutch for powerful boring quill feed
»
»
digitale speed indicator
»
»
cooling device
»
»
automatic tool mounts
»
»
3-axis-digital readout
