box column drill presses
Very powerful industrial box-frame-column drilling machine
with new design, proven drilling head and a large quill stroke.
BKM 5150
BKM 7150
drilling capacity in steel
50 mm
63 mm
milling performance in Steel
-
80 mm
threadcutting volume
M42
M42
spindle speeds
40 - 1600 U/min stepless
2 Getriebesteps
1. Stufe 48 - 310 U/min,
2. Stufe 310 - 2000 U/min
table size
800 x 600 mm
1020 x 380 mm
size of t-slots
14 mm (M12)
14 mm (M12)
drilling feeds
0.08 - 0.50 mm/U 6 Steps
0.08 - 0.05 6 Steps
height adjustment drilling
head
750 mm
530 mm
tool mounts
Morse Konus 4
BT 40
quill stroke
280 mm
240 mm
distance spindle nose -
column
450 mm
450 mm
distance spindle nose - work
table
max 850 mm
max 680 mm
power of engine
4 kW/400 Volt
3,7 kW 400 Volt
movement longitudinal X
510 mm
movement cross Y
380 mm
weight
1350 kg
1800 kg
dimensions
1490 x 950 x 2370 mm
1700x1510x2250 mm
Features
»
»
extremly wide and solid box frame construction made of cast iron for
heavy duty applications,
»
»
prism guideways for drilling head, motorized positioning of the drilling
heades, stepless speed in 2 gear steps for optimal power transmis-
sion, threading attachment with adjustable depth indicator
»
»
central lubrication for extended lifecycle of the guideways
»
»
autofeed for quill
»
»
electromagnetic clutch for powerful boring quill feed
»
»
digitale speed indicator
»
»
cooling device
»
»
automatic tool mounts (nur BKM7163)
»
»
stepless feeds in X+Y axis (nur BKM7163)
»
»
3-axis-digital readout (nur BKM7163)
Accessories
»
»
drill chuck arbor
