drilling machines
High-quality drill presses for industrial use.
The machines are also suitable for multi-shift operation.
BKM 5040
BKM 5032
BKM 5030
drilling capacity in steel
40 mm in ST 45
32 mm
30 mm
threadcutting volume
M24
M20
M20
spindle speeds
42 - 2050 U/min
12 Steps 125 - 3030 U/min 12 Steps 125 - 3030 U/min
distance spindle nose -
column
360 mm
320 mm
260 mm
quill feed
0,1/0,2/0,3/0,4 mm/U
0,1/0,2/0,3 mm/U:
0,1/0,2/0,3 mm/U
0,1/0,2/0,3 mm/U
table size
470 x 550 mm
420 x 350mm
working area
410 x 380 mm
500 x 420 mm
335 x 340 mm
tool mounts
Morse Konus 4
Morse Konus 4
Morse Konus 3
quill stroke
180 mm mit digitaler Tiefen-
anzeige
155 mm
135 mm
diameter of coloumn
160 mm
120 mm
135 mm
distance spindle nose - base
1200 mm
power of engine
2,2/2,8 kW 400 Volt
1,0/1,2 kW/400 Volt
0,8/1,1 kW/400 Volt
weight
700 kg
540 kg
380 kg
dimensions
1010 x 580 x 2330 mm 880 x 515 x 2220 mm 870x550x2220 mm
Features
»
»
digital depth measuring device
»
»
drilling table with t-slots
»
»
easy and fast speed changes by gear shift
»
»
smooth running by hardened and ground gearwheels
operating in oil-bath
»
»
threading attachment
»
»
electromagnetic clutch for boring quill feed
»
»
autofeed for quill
»
»
cooling device
»
»
electric drive for table height adjustment (nur BKM5040)
Accessories
»
»
drill chuck arbor
»
»
drill chuck
»
»
adapterMK4/MK3 and MK3/MK2
Abbildungen können abweichen.Technische Daten können ohne vorherige Ankündigung geändert werden. Keine Haftung für Irrtümer und Druckfehler.Alle Preise on request.
