BKM 3025V
BKM 3035V
drilling capacity in steel
25 mm
32 mm
thread cutting
max. M12
max. M20
distance spindle nose - column
230 mm
320 mm
spindle speeds
80 - 1600 U/min stepless
85 - 1800 U/min stepless
table size
400 x 320 mm
500 x 420 mm
tool mounts
Morse Konus 3
Morse Konus 4
quill stroke
110 mm
160 mm
diameter of coloumn
100 mm
120 mm
size of t-slots
14 mm
14 mm
distance spindle nose - base
1180 mm
1180 mm
power of engine
1. Stufe 0,70 kW und 2 Stufe 1.3 kW 0,85/1.5 kW
automatic feeds
0.1;0.2;0.3
weight
250 kg
500 kg
dimensions
820 x 530 x 1715 mm
965x515x1920 mm
drilling machines
Industrial drill press with variable speed for constant power transmission.
Features
»
»
threading attachment
»
»
cross table with adjustable guide ways
»
»
boring quill feed
»
»
gearbox
»
»
cooling device
