bed type milling machine FKM 760
Heavy milling machine with drilling function and tilting head and synchronous milling capability.
FKM 760
spindle speeds
94 - 2256 U/min 16 Steps
drilling capacity in steel
max. 50 mm
drilling feeds
0,1/0,15/0,3 mm/U
movement longitudinal X
650 mm (Autofeed 600 mm)
movement cross Y
360 mm
movement in Z
400 mm
automatic table feeds
24-720 mm/min (8 Steps)
tool mounts
ISO 40 (SK 40)
distance spindle nose - work
table
120-620 mm
working area
1220 x 360 mm
quill stroke
180 mm
size of t-slots
T14
power of engine
1,5/2,4 kW 400V
weight
1610 kg
dimensions
1730 x 1730 x 2300 mm
Features
»
»
gears hardend and ground
»
»
threading attachment
»
»
automatic feed X- and Y-axis
»
»
motorized Z-axis adjustment
»
»
automatic boring quill feed
»
»
electrical height adjustment of the milling head
»
»
central lubrication
»
»
big control panel
»
»
cooling device
»
»
3-axis digital readout
Accessories
»
»
ISO 40 collet chuck set
»
»
drilling chuck with ISO 40 arbor
