Massive Bed Type Milling Machine with easy to use pivotable universal milling head system
Huron. The massive machine bed made of high quality cast iron and specially hardened, robust
guideways ensure precise operation and a long service life. With a table working area of 2500 x
575 mm and the high table load capacity of 3000 kg a multitude of applications are possible.
bed type milling machine FKM 8200
FKM 8200
table dimensions
2500x575 mm
longitudinal movementachse (X)
1800 mm
travel transverse axis (Y)
600 mm
travel vertical axis (Z)
900 mm
tool mounts
ISO 50/Steilkegel 50
table load max.
3000 kg
t-slots amount
3 St
t-slots width
22 mm
t-slots distance
152 mm
feeds X-axis
20 - 2200 mm/min
feeds Y-axis
20 - 2200 mm/min
feeds Z-axis
12 - 1320 mm/min
rapid feed X-axis
3000 mm/min
rapid feed Y-axis
3000 mm/min
rapid feed Z-axis
1800 mm/min
speed range
40 - 1200 U/min
spindlenose-tablesurface
min/max
50 - 950 mm
range of swivelhead
360
power of main motor
11 kW
enginepower of feed
2,9 kW
enginepower of cooling pump
0,09 kW
weight
12800 kg
dimensions
4300x3200x3300 mm
Features
»
»
hydraulic Brake in all axis
»
»
Trittschutz zur erleichterten Werkstückbeladung
»
»
cooling device
»
»
3-axis-digital readout
Accessories
»
»
milling chuck ISO 50 inkl. collets
»
»
adapterISO 50/MK4
Universalfräskopf Typ Huron. Durch die 2 Schwenkebenen ist
er nahezu auf jeden räumlichen Winkel einstellbar.
