Very sturdy vertical milling machine in massive box frame construction with flat bed guideways
for precision machining. The machine body is made of very high quality meehanite cast iron.
bed type milling machine FKM 5140
FKM 5140
sizes of worktable
1400x400 mm
spindle speeds
40 - 1800 U/min
movement longitudinal X
800 mm
movement cross Y
400 mm
movement in Z
500 mm
height adjustment milling head
150 - 650 mm
tool mounts
SK 50
quill stroke
105 mm
rapid feed X/Y/Z-axis
1670 mm/min
feeds for X,Y,Z axis
18 - 627 mm/min
range of swivelhead
+/- 30
distance spindle nose - work table
150 - 650 mm
size of t-slots
3x18x100 mm
distance spindle nose - column
510 mm
power of main motor
7,5 kW
power of engine
0,75 kW
enginepower of feed
0,75 kW
enginepower of cooling pump
0,04 kW
flow rate cooling pump
12 l/min
weight
3660 kg
dimensions
2290 x 1770 x 2120 mm
Features
»
»
very high table load
»
»
left/right 30° swivel-mounted milling head
»
»
optimal spindle speed range with high torque
»
»
stepless speed control
»
»
flat bed guideways for best stability at high cutting depth
»
»
adjustable, hardened and ground guideways
»
»
big dimensioned boring quill with manual feeding
»
»
standard spindle break
»
»
central lubrication
»
»
cooling device
»
»
3-axis digital readout
Accessories
»
»
ISO 50 milling chuck
»
»
ISO 50 reducing bushes MK4
»
»
MK3 and MK2
»
»
machine vice 160 mm
