electric shearing machines
Economic, electrical standard plate shear model with digital
back gauge for fast working.
TKM 1350/3,5 E TKM 2000/3,5 E TKM 2500/3,5 E TKM 3000/3,5 E TKM 3500/2 E
sheet thickness
ST 42 (max.) 3,2 mm St. 42 (max.)3 mm St. 42 (max.)3,5 mm St. 42 (max.)3,5 mm St. 42 (max.)2 mm
sheet length
(max.) 1320 mm
(max.)2050 mm
(max.)2550 mm
(max.) 3000 mm
(max.) 3500 mm
back gauge
650 mm
600 mm
1000 mm
650, optional 1000 mm 650, optional 1000 mm
cuting angle
2,25
2.2
2
1,30
1,30
power of engine
2,2 kW
5,5 kW
7,5 kW
9 kW
9 kW
strokes per minute
(Automatikbetrieb) 35 H (Automatikbetrieb) 45 H (Automatikbetrieb) 45 H (Automatikbetrieb) 45 H
working table height
850 mm
800 mm
800 mm
800 mm
weight
1450 kg
2150 kg
2580 kg
2500 kg
dimensions
1800x1900x1500 mm 2400x1350x1200 mm 2900x1350x1200 mm 3599x2448x1290 mm 4200x2448x1240 mm
Features
»
»
hold-down system
»
»
high-strength hardened and ground cutting blades
»
»
electric back gauge
»
»
digital measuring device for back gauge
»
»
Plate cover protection
»
»
Light for cutting line
»
»
single stroke and continuous stroke operation mode
»
»
contact protection
»
»
lateral stop with measuring scale
can be delivered with PLC-control
