Pictures may differ. Specifications are subject to change without notice. No liability for errors and printing mistakes.All prices on request.
TKM 2000/4
TKM 2000/6
TKM 2500/4
TKM 2500/6
TKM 2500/8
TKM 2500/10
TKM 2500/12
TKM 2500/16
TKM 2500/20
TKM 2500/25
TKM 3200/4
TKM 3200/6
TKM 3200/8
TKM 3200/10
sheet thickness
4 mm 6 mm 4 mm 6 mm 8 mm 10 mm 12 mm 16 mm 20 mm 25 mm 4 mm 6 mm 8 mm 10 mm
cutting length
2000
mm
2000
mm
2500
mm
2500
mm
2500
mm
2500
mm
2500
mm
2500
mm
2500
mm
2500
mm
3200
mm
3200
mm
3200
mm
3200
mm
cuting angle
1.30
1.30
1.30
1.30
1.30
1.30
1.30
2
3
3.12
1.30
1,3
1.30
1.30
strokes per
minute
20 H/
min
20 H/
min
20 H/
min
18 H/
min
12 H/
min
10 H/
min
16 H/
min
8 H/min 5 H/min 5 H/min 18 H/
min
14 H/
min
10 H/
min
10 H/
min
back gauge
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 800
mm
20 - 800
mm
20 - 800
mm
20 - 800
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
power of engine
4 kW 7,5 kW 4 kW 7,5 kW 11 kW 18,5 kW 18,5 kW 22 kW 30 kW 45 kW 5,5 kW 7,5 kW 11 kW 18,5 kW
weight
3000 kg
3300 kg 5200 kg 7000 kg 7000 kg 8600 kg 10600
kg
13500
kg
22800
kg
5100 kg 6700 kg 8300 kg 8300 kg
dimensions
2800x1500x1600
mm
2580x1530x1600
mm
3350x1450x1600
mm
3350x1600x1650
mm
3400x1850x1850
mm
3400x1900x1850
mm
3400x1850x2000
mm
3400x2000x2250
mm
6900x2950x2750
mm
3400x2550x2700
mm
3900x1700x1800
mm
3900x1750x1800
mm
3900x1850x1950
mm
4000x1850x1950
mm
TKM 3200/12
TKM 3200/16
TKM 3200/20
TKM 3200/25
TKM 4000/4
TKM 4000/6
TKM 4000/8
TKM 4000/12
TKM 4000/16
TKM 5000/4
TKM 5000/6
TKM 5000/12
TKM 6000/6
TKM 6000/8
sheet thickness
12 mm 16 mm 20 mm 25 mm 4 mm 6 mm 8 mm 12 mm 16 mm 4 mm 6 mm 12 mm 6 mm 8 mm
cutting length
3200
mm
3200
mm
3200
mm
3200
mm
4000
mm
4000
mm
4000
mm
4000
mm
4000
mm
5000
mm
5000
mm
5000
mm
6000
mm
6000
mm
cuting angle
1.30
2
2.30
3
1.30
1.30
1.30
1.30
2
1.12
1.30
1.30
1.30
1.30
strokes per
minute
14 H/
min
8 H/min 5 H/min 5 H/min 16 H/
min
14 H/
min
8 H/min 10 H/
min
6 H/min 14 H/
min
10 H/
min
8 H/min 10 H/
min
10 H/
min
back gauge
20 - 800
mm
20 - 800
mm
20 - 800
mm
20 - 800
mm
20 - 600
mm
20 - 600
mm
20 - 600
mm
20 - 800
mm
20 - 800
mm
20 - 600
mm
20 - 600
mm
20 - 800
mm
20 - 800
mm
20 -
1000
mm
power of engine
18,5 kW 22 kW 37 kW 45 kW 5,5 kW 7,5 kW 11 kW 18,5 kW 22 kW 7,5 kW 11 kW 18,5 kW 11 kW 22 kW
weight
10800
kg
13200
kg
18200
kg
22800
kg
7200 kg 7200 kg 9700 kg 13200
kg
17000
kg
10500
kg
13300
kg
17800
kg
18000
kg
24000
kg
dimensions
4000x1950x2000
mm
4100x2100x2550
mm
4200x2460x2850
mm
4000x2550x2700
mm
4750x1750x1800
mm
4750x1750x1800
mm
4800x1950x1900
mm
4800x2050x2150
mm
5000x2300x2550
mm
5750x1750x1800
mm
5750x1750x2000
mm
5900x2270x2400
mm
6900x2200x2350
mm
6900x2750x2600
mm
hydraulic shearing machines
Powerful hydraulic swing beam guillotine shears.
Features
»
»
all moving parts are mounted with bearings
»
»
parallel blade guides for high cutting precision
»
»
high-strength hardened and ground blades made of
steel alloy
»
»
lateral stop and front supporting arms
»
»
single stroke and continuous stroke function
»
»
hold-down system with secure contact protection
»
»
closed protection cage
